Client Side API Mashups With CORS

At Heroku we have APIs for pretty much everything. Need logs for an app? Is that database available? You just beat someone at ping pong? There’s an API for that. Having such rich datasets available is great. It allows us to build dashboards with mashups of different datasets and serve them from a web browser.

Here are some of the techniques implemented in order to wire up a Backbone.js application speaking to remote hosts in a secure manner. We will explore Cross-Origin Resource Sharing (CORS) as well as HMAC based auth tokens with cryptographically timestamped data that an attacker wouldn’t be able to auto-replay. The end goal is to have an application running on a browser, and securely request data from an API running on a remote host.

The first problem when issuing XHR requests across hosts will be the same-origin policy violation. Go ahead, issue an AJAX request against a remote host. The browser should fail with an error similar to the following:

1
XMLHttpRequest cannot load https://some.remote.com. Origin https://your.site.com is not allowed by Access-Control-Allow-Origin

This is where Cross Origin Resource Sharing (CORS) comes in. The way it works is that the Origin (the client) will issue what’s called a pre-flight request, asking the server “hey, can I make a request with HTTP verb foo to path /bar with headers x-baz?”, to which the server responds, “Sure, bring it!”, or “No, you may not”. This pre-flight request is made to the same path as the actual request, but the HTTP OPTIONS verb is used instead. The server responds with the following headers, should the request be allowed:

  • Access-Control-Allow-Origin: Specifies what Origins are allowed remote XHR requests to be made against this server. Allowed values include a URL (eg: https://your.site.com), a comma separated list of URLs, or an asterisk indicating all origins are allowed.
  • Access-Control-Allow-Headers: Specifies a comma separated list of headers that the Origin is allowed to include in requests to this server. There are many reasons to include custom headers - we’ll see an example of this further down.
  • Access-Control-Max-Age: This is optional, but it allows the browser to cache this response for the given number of seconds, so browsers will save themselves the pre-flight request any subsequent times. Freely set it to a large number, like 30 days (2592000)

There are more headers that allow you to whitelist and otherwise control access to the resource. Be sure to read up on CORS.

Thus, a Sinatra app acting as the remote end of the system can respond to pre-flight OPTIONS requests like so:

1
2
3
4
5
options '/resources' do
headers 'Access-Control-Allow-Origin' => 'https://your.site.com',
'Access-Control-Allow-Headers' => 'x-your-header',
'Access-Control-Max-Age' => '2592000'
end

Inclusion of the Allow Origin and Allow Headers headers is also necessary on responses to any other remote XHR requests. We can extract the headers directive to a helper and use it on both pre-flight and other requests:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
options '/resources' do
cors_headers
headers 'Access-Control-Max-Age' => '2592000'
end
post '/resources' do
cors_headers
# do_work
end
private
def cors_headers
headers 'Access-Control-Allow-Origin' => 'https://your.site.com',
'Access-Control-Allow-Headers' => 'x-your-header'
end

And just like that, browsers can now issue XHR requests against remote APIs. Of course, there is no authentication in place yet.

We will implement an HMAC based auth token mechanism. Both the remote server and your app share a secret. This secret is used to generate a token containing a timestamp that is used for validating token recency. The HMAC digest is a signature that is generated with the shared secret, and it can be used to verify the authenticity of the entity that generated the token. It answers the question of whether the the client of the API request is authentic.

To generate the token, we create a JSON document containing an issued_at timestamp, and we calculate its sha256 HMAC token using the secret known to both parties. Finally, we append this signature to the JSON document and we base64 encode it to make it safe to send over the wire. Here’s an example implementation:

1
2
3
4
5
6
7
8
9
require 'openssl'
require 'json'
require 'base64'
def auth_token
data = { issued_at: Time.now }
secret = ENV['AUTH_SECRET']
signature = OpenSSL::HMAC.hexdigest('sha256', JSON.dump(data), secret)
Base64.urlsafe_encode64(JSON.dump(data.merge(signature: signature)))
end

This token is used on the API server to authenticate requests. The client can be made to send a custom header, let’s call it X_APP_AUTH_TOKEN, which it must be able to reconstruct the token from the JSON data, and then validate that the request is recent enough. For example in a Sinatra application:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
def not_authorized!
throw(:halt, [401, "Not authorized\n"])
end
def authenticate!
token = request.env["HTTP_X_APP_AUTH_TOKEN"] or not_authorized!
token_data = JSON.parse(Base64.decode64(token))
received_sig = token_data.delete('signature')
regenerated_mac = OpenSSL::HMAC.hexdigest('sha256', JSON.dump(token_data), ENV['AUTH_SECRET'])
if regenerated_mac != received_sig || Time.parse(token_data['issued_at']) > Time.now - 2*60
not_authorized!
end
end

In the above code, we consider a token invalid if it was issued more than 2 minutes ago. Real applications will probably include more data in the auth token, such as the email address or some user identifier that can be used for auditing and whitelisting. All of the above data token generation and verification has been extracted to a handy little gem called fernet. Do not reimplement this, just use fernet. In addition to HMAC signature, fernet also makes it easy to encrypt the message’s payloads, which opens it up for other interesting use cases.

The authenticate! method must be invoked before serving any request. This means that the auth token must be included on every request the client makes. There are many ways of doing this. One approach, if you’re using JQuery to back Backbone.sync(), is to use its $.ajax beforeSend hook to include the header, as can be seen in the following coffeescript two-liner:

1
2
$.ajaxSetup beforeSend: (jqXHR, settings) ->
jqXHR.setRequestHeader "x-app-auth-token", App.authToken

App.authToken can come from a number of places. I decided to bootstrap it when the page is originally served, something like:

1
2
3
<script type="text/javascript">
App.authToken = "<%= auth_token %>";
</script>

In addition to that, it should be updated in an interval, so that on a single page app, that doesn’t request any page refreshes, the auth token is always fresh and subsequent API requests can be made.

The final client side code that provides the auth token and keeps it updated looks like so:

1
2
3
4
5
6
7
8
9
<script type="text/javascript">
App.authToken = "<%= auth_token %>"; //bootstrap an initial value
App.refresh_auth_token = function() {
$.getJSON('/auth_token', function(data) {
App.authToken = data.token; //request updated values
})
};
window.setInterval(App.refresh_auth_token, 29000); //every 29 seconds
</script>

The /auth_token server side endpoint simply responds with a new valid token.

The fernet token expires every minute by default. I decided to update it every 29 seconds instead so that it can be updated at least twice before it has a chance to hold and use an expired token against a remote API.

In this app, the server side is used for one thing only: user authentication. The way it works is that when a request is made, the sinatra app performs oauth authentication against our google apps domain. Once the oauth dance has suceeded, the app generates a token that is handed on to the client for authenticating against backend, remote APIs.

This whole setup has worked great for some months now.
